Point Pod Connect - 2 Power and 3 Charging USB Motorized Pop Up Outlet with  Custom Stone Top, Black Ring

The Point Pod Connect PPCV815B is a kitchen countertop approved pop up outlet that conceals your power and USB connectors by utilizing a piece of your countertop as the top.  What makes this kitchen power pop up outlet so unique, is that it gives you the ability to keep the clean aesthetic look of your stone or wood countertop by creating a flush counter installation. It offers a discreet and functional solution and a seamless aesthetic design that allows the use of the same material as your counter to be fitted on the top of the Point Pod. This outlet is a popular choice for homeowners and designers who value both functionality and appearance, while still meeting code.

Reliable Motorized Lifting with No Buttons
What sets this model apart from the competition is that it is motorized!  Simply press the top when you need access to your two outlets or three USB charging ports, and the top of the unit smoothly and quietly rises up. Press the top again and the unit retracts down back flush to your countertop. There are no buttons! Softly touch the fitted stone cap and the unit will smoothly retract back into your countertop. Designed with safety in mind, the Point Pod Connect features a programmed sensor that allows the unit to sense resistance (fingers or a hand for example), that might be in the way, and will stop the unit from lowering and immediately rise back up.

There are two 15A power plugs, two 3A USB-C ports, and one 2.4A USB-A port. The USB charging ports have a max total amperage of 6A when multiple USB devices are plugged in.

Installs in Any Direction

Realizing the limitations of a standard drop down pop up outlet - the Point Pod Connect has been designed to be installed in any direction! This means if your below counter space is too tight or you do not want to give up under cabinet space, you can now install these units upside down or sideways. Allowing for a "Pop Down" electrical outlet, or a "Pop Out" by installing the unit horizontally.

Custom Round Insert Installs Flush to the Countertop

The Point Pod is the only round model where you put the stone cut-out back in the top for a seamless fit. By using a piece of the same countertop material as the top, you can create a matching and camouflaged pop up in your countertop. The fabricator will need to cut out a 4" outside diameter hole size, while the inner disc that will be installed in the cup needs to be 3 11/16". This disc can have a thickness between 1" and 1.25". This is typically done with a hole saw or a water jet. That disc that is cut is then installed in the cup, the cup ring is only .05" thick and barely noticeable.

Approved for Countertop Installations

The Point Pod Connect is ETL listed and approved for USA installations into countertops, as well as CSA approved for countertop installations in Canada. The ETL listing is approved for UL listing 962A, and CSA is approved for C22.2 No. 308. The unit is IP44 rated for water ingress protection, it also has water diversion built in so any spills will be diverted away from the unit.

The outlet is rated for 15 Amps and also has tamper-resistant plugs, making the receptacles tamper-proof for children.

Primary Point Pod Connect Features

  • IP44 Kitchen Counter Top Approved Rating
  • Motorized Lift - Single Press Top
  • "Hidden" Installation - Uses Your Countertop as the lid
  • Installs in any vertical or horizontal direction
  • 15 Amp Rated
  • Outlets - 2 US Power, 1x USB-A, 2x USB-C Ports
  • Single 6' Power Cable for US wall outlet

***IMPORTANT 5-STEP CHECKLIST BEFORE ORDERING***

1. Do you have the space below your countertop to install? The unit will take up 17" of space under a 3cm countertop. The unit will also need 6 5/16" of width space for the flange under the countertop, the rest of the body under the counter is 4".

2. Can the electrician put in a GFCI outlet, or an outlet on a GFCI circuit where needed?

3. Will you have access after installing the pop up outlet to plug in the 6' power cord?

4. Can the stone fabricator make the specialized cuts in the countertop? It is recommended the cuts be made prior to installation, but a competent installer with the correct tools can make the cuts after installation. Please see the installation PDF.

5. If you are located in Canada, your local code might require a 20A outlet. This model is 15A.

If you have any questions, we are always here to help! Reach out via chat, phone, or email.

-Point Pod Connect Specifications (PDF)
-Installation Manual (PDF)


Specifications:

    • Model: PPCV815B - Point Pod Connect
    • Color: Black Top Ring, Black Shell, Black Outlets
    • Outlet: 15 Amps, tamper resistant
    • IP Rating: IP44 Water Protection
    • Indoor Use Only
    • Installation Hole Diameter: 4" Diameter
    • Lifting Method: Motorized Lift - Single Press Top
    • Outlets: 2x US Power Outlets, 1x USB-A, 2x USB-C
    • Power Cable Length: 6ft
    • Space Below Surface: 18 (in) depth, 6 and 5/16 (in) in diameter at mounting flange, 4 (in) for body
    • Cutout disc size: 3 11/16"
    • Cutout disc thickness: 1" to 1.25"
    • Trim ring thickness: .05"
    • Works in counter thickness: 3cm
    • ETL listed for USA
    • CSA approved for Canada
    • Plug: US Plug
    • Rated Voltage: 125ac 60Hz
    • Rated Current: 15A, 1875w Total
    • Total load connected not to exceed rating
    • Operating Temperature: 0 - 40 C, 32 - 104 F
    • USB Charger: (internal, built in)
    • Input : 100-240V ~ 50/60Hz ; 0.5A
    • Output: USB-A: 5V3A USB-C: 5V3A
    • ETL Listed, UL 962A & CSA C22.2
    • US Patent # US 10 777 985 B2
    • Materials: Polyamide, ABS, Anodized Aluminium
    • Plug power into a GFI outlet
    • Install using a licensed electrician
    • Consult with electrician/inspector before ordering
    • Designed for indoor installations only
    • Tested to 30,000 open/close cycles
    • Weight: 6.75 pounds
    • Warranty: 24 months

    -Point Pod Connect Specifications (PDF)
    -Installation Manual (PDF)


    • Model: PPCV815B - Point Pod Connect
    • Color: Black Top Ring, Black Shell, Black Outlets
    • Outlet: 15 Amps, tamper resistant
    • IP Rating: IP44 Water Protection
    • Indoor Use Only
    • Installation Hole Diameter: 4" Diameter
    • Lifting Method: Motorized Lift - Single Press Top
    • Outlets: 2x US Power Outlets, 1x USB-A, 2x USB-C
    • Power Cable Length: 6ft
    • Space Below Surface: 18 (in) depth, 6 and 5/16 (in) in diameter at mounting flange, 4 (in) for body
    • Cutout disc size: 3 11/16"
    • Cutout disc thickness: 1" to 1.25"
    • Trim ring thickness: .05"
    • Works in counter thickness: 3cm
    • ETL listed for USA
    • CSA approved for Canada
    • Plug: US Plug
    • Rated Voltage: 125ac 60Hz
    • Rated Current: 15A, 1875w Total
    • Total load connected not to exceed rating
    • Operating Temperature: 0 - 40 C, 32 - 104 F
    • USB Charger: (internal, built in)
    • Input : 100-240V ~ 50/60Hz ; 0.5A
    • Output: USB-A: 5V3A USB-C: 5V3A
    • ETL Listed, UL 962A & CSA C22.2
    • US Patent # US 10 777 985 B2
    • Materials: Polyamide, ABS, Anodized Aluminium
    • Plug power into a GFI outlet
    • Install using a licensed electrician
    • Consult with electrician/inspector before ordering
    • Designed for indoor installations only
    • Tested to 30,000 open/close cycles
    • Weight: 6.75 pounds
    • Warranty: 24 months


    -Point Pod Connect Specifications (PDF)
    -Installation Manual (PDF)


    Shipping Policy
    This item qualifies for free ground shipping to anywhere in the USA and Canada. In-stock orders are shipped the same business day Monday-Friday from Boise, ID if ordered by 6pm EST.
    Return Policy
    If you are not completely satisfied with your purchase you may return this item for a full refund of the merchandise total, the return request must be made within 45 days from the order date. Please note that you are responsible for all return shipping charges unless the item is defective or damaged. Return credits are issued within 5 business days to your original method of payment once the item is received and inspected.
    Return Eligibility
    Items must be in new condition and in the original packaging to qualify for a full refund (please do not modify the product in any way). If these conditions are not met, then the return could be subject to a restocking fee, or the product sent back to the sender.

    QUESTIONS & ANSWERS

    Ask a Question
    • Are these outlets Tamper Resistant, for USA install? Do not see it listed in specs on the website, or noted on the cut sheet. Please confirm. Thank you.

      They are Tamper Resistant, if you zoom in on the outlet pics you can see the TR letters on the outlet.

    • Are the outlets tamper resistant?

      Yes they ate tamper resistant.
